Fitting rating curves

Source: vignettes/fitting.Rmd
fitting.Rmd

This vignette walks through the ways CSHShydRometry fits a rating curve: the relationship between a river’s stage (its water level) and its discharge (the flow). It starts by looking at the data, which tells you which model to use, then fits single-segment curves in several ways, and ends with a curve in two segments. How sure we can be about the fitted curves is the subject of vignette("uncertainty").

The gaugings

A rating curve is fitted to gaugings: occasions when both stage and discharge were measured. The package comes with 93 gaugings from the Thompson River near Spences Bridge, British Columbia, made between 1994 and 2024.

thompson
#> # A tibble: 93 × 5
#>    date       stage discharge uncertainty_pct rating_table
#>    <date>     <dbl>     <dbl>           <dbl> <chr>
#>  1 1994-03-29 1.01        266              NA NA
#>  2 1994-05-20 5.58       2000              NA NA
#>  3 1994-09-15 1.76        451              NA NA
#>  4 1995-03-17 0.645       197              NA NA
#>  5 1995-06-09 6.40       2440              NA NA
#>  6 1996-06-27 6.03       2290              NA NA
#>  7 1996-08-22 3.29        969              NA NA
#>  8 1997-06-09 7.78       3460              NA NA
#>  9 1998-04-21 1.97        506              NA NA
#> 10 1998-05-19 5.78       2180              NA NA
#> # ℹ 83 more rows

Rating curves are drawn with stage on the vertical axis:

plot(stage ~ discharge, data = thompson,
     xlab = "Discharge (m³/s)", ylab = "Stage (m)")

Which gaugings to use

A rating curve describes the river while its channel stays the same. Channels change, through erosion, deposition or work on the control, so a curve is usually fitted to gaugings from one period of stable conditions.

One way to check is to fit a model to the entire dataset and see whether the gaugings systematically miss the curve over time. We’ll build that model here with rc_powerlaw_log(), which is explained below. What matters here are its residuals, which are on the log scale, so multiplied by 100 they are roughly percentage departures from the curve.

fit_all <- rc_powerlaw_log(discharge, stage, data = thompson)
departure <- residuals(fit_all)

plot(thompson$date, 100 * departure,
     xlab = "Date of gauging", ylab = "Departure from the curve (%)")
abline(h = 0, col = "grey")
lines(lowess(thompson$date, 100 * departure, f = 0.3), lwd = 2)

The curve’s error depends on when the gaugings were made: its predictions are too low in the 1990s, too high in the 2000s, and so on. The Water Survey’s own rating changed too, as the rating_table column records.

For a rating to use in practice, you would choose a stable period and keep only its gaugings, for example with subset(thompson, rating_table == "11"). This vignette uses all 93 gaugings to illustrate the methods, which is fine for that purpose, but the fitted curves average over several ratings.

Looking at the scatter

Before choosing a model, look at how the gaugings scatter about a fitted curve. A loess smoother makes few assumptions about the curve’s shape, so its residuals show the scatter fairly.

Fit the model and get the fitted values and the residuals.

smooth <- rc_loess(discharge, stage, data = thompson)
fitted_q <- fitted(smooth)
residual_q <- residuals(smooth)

Now check whether the residuals have an even spread about the curve.

Show the code
op <- par(mfrow = c(1, 2))
plot(
  fitted_q,
  residual_q,
  xlab = "Fitted discharge (m³/s)",
  ylab = "Residual (m³/s)",
  main = "Residuals"
)
abline(h = 0, col = "grey")
plot(
  fitted_q,
  100 * residual_q / fitted_q,
  xlab = "Fitted discharge (m³/s)",
  ylab = "Residual (%)",
  main = "Relative residuals"
)
abline(h = 0, col = "grey")
par(op)

The residuals fan out as the flow grows, while the relative residuals stay roughly even. The scatter is roughly proportional to the flow: a constant percentage, not a constant amount. That matters for the fit, because ordinary least squares doesn’t perform as well when the residuals scatter more with increasing flow.

There are two ways to allow for it, both below: model the variance, or fit on the log scale.

A power law on the original scale

The usual rating curve is a power law, Q=a(h−c)bQ = a (h - c)^b, where QQ is discharge and hh is stage. The model parameters are aa, bb, and cc, with cc being the offset: the stage at which the flow would stop. rc_powerlaw() fits this model by least squares on the original scale:

fit <- rc_powerlaw(discharge, stage, data = thompson)
coef(fit)
#>          a          b          c
#> 80.6686509  1.7131161 -0.9044142

To improve the least squares estimation, the variance argument lets you specify how you think the scatter changes with the flow. By default it is the same at every flow (var_none()). With var_prop() its standard deviation is assumed proportional to the flow, which suits the Thompson gaugings better. Either way, the fit weights each gauging by the reciprocal of its variance.

fit_prop <- rc_powerlaw(
  discharge,
  stage,
  data = thompson,
  variance = var_prop()
)
coef(fit_prop)
#>         a         b         c
#> 52.487716  1.879973 -1.303340

It’s worth knowing about the extra gymnastics this takes. When we say that the standard deviation of the flow is proportional to the flow itself, we don’t mean the observed flow, but the average flow at a given stage: the thing being predicted. That’s because we’re talking about the (vertical) scatter around the curve. So the weights depend on the fitted curve, and the fitted curve depends on the weights. To deal with this, the fit is repeated, reweighting each time, until it settles; hence “iteratively reweighted least squares” (IRLS). Here is the number of iterations it took:

fit_prop$irls$iterations
#> [1] 5

var_power() goes one step further than var_prop(), and estimates the power of the flow to which the scatter is proportional:

fit_power <- rc_powerlaw(
  discharge,
  stage,
  data = thompson,
  variance = var_power()
)
fit_power$variance$exponent
#> [1] 0.999845

An estimated power close to 1 supports var_prop(). The estimate can be unstable with few gaugings, so compare it with the fit under var_prop().

When each gauging comes with its own reported uncertainty, var_spec() uses it directly; there is an example with the two-segment curve below. See ?variance for all the variance schemes.

A power law on the log scale

Taking logs turns the power law into a straight line in log⁡(h−c)\log(h - c):

log⁡Q=log⁡a+blog⁡(h−c) \log Q = \log a + b \log(h - c)

Equal scatter on the log scale is scatter proportional to the flow, so rc_powerlaw_log() allows for the fanning out by its choice of scale, with no variance scheme:

fit_log <- rc_powerlaw_log(discharge, stage, data = thompson)
coef(fit_log)
#>         a         b         c
#> 52.398628  1.880339 -1.304109

Back on the original scale, this curve estimates the geometric mean discharge at each stage, which is a little below the arithmetic mean. fit_log$a_corrected holds two versions of aa corrected for that.

cc is the offset. For a single power law it is the stage at which the flow would stop, but with several segments it no longer is, so the package calls it the offset throughout. If it is known, say from a survey of the control, give it as offset and only aa and bb are estimated. rc_powerlaw() takes offset too.

coef(rc_powerlaw_log(discharge, stage, data = thompson, offset = -1.3))
#>         a         b         c
#> 52.655954  1.878378 -1.300000

Other curve shapes

Not every rating follows a power law. rc_poly() fits a polynomial in stage, and rc_loess() a smooth curve with no set shape. Both accept the same variance schemes as rc_powerlaw(), except var_power().

fit_cubic <- rc_poly(discharge, stage, data = thompson, degree = 3)
fit_smooth <- rc_loess(discharge, stage, data = thompson)

Comparing the fits

Every fit has a predict() method, so the curves can be compared at chosen stages:

at <- c(1, 4, 8)
predict(fit_prop, new_stage = at)
#> # A tibble: 3 × 2
#>   stage   fit
#>   <dbl> <dbl>
#> 1     1  252.
#> 2     4 1208.
#> 3     8 3476.
predict(fit_cubic, new_stage = at)
#> # A tibble: 3 × 2
#>   stage   fit
#>   <dbl> <dbl>
#> 1     1  249.
#> 2     4 1226.
#> 3     8 3399.

predict() returns the same columns for every model, so the results stack. With the dplyr package (not a dependency of this one), bind_rows() can label each row with its model:

dplyr::bind_rows(
  power_prop = predict(fit_prop, new_stage = at),
  cubic = predict(fit_cubic, new_stage = at),
  .id = "model"
)
#> # A tibble: 6 × 3
#>   model      stage   fit
#>   <chr>      <dbl> <dbl>
#> 1 power_prop     1  252.
#> 2 power_prop     4 1208.
#> 3 power_prop     8 3476.
#> 4 cubic          1  249.
#> 5 cubic          4 1226.
#> 6 cubic          8 3399.

Without new_stage, predict() covers the range of the gaugings, which makes it easy to draw the curves:

plot(stage ~ discharge, data = thompson, col = "grey50",
     xlab = "Discharge (m³/s)", ylab = "Stage (m)")
lines(stage ~ fit, data = predict(fit_prop), lwd = 2)
lines(stage ~ fit, data = predict(fit_log), lwd = 2, lty = 2)
lines(stage ~ fit, data = predict(fit_cubic), lwd = 2, lty = 3)
legend("bottomright", c("Power law, var_prop()", "Power law, log scale",
       "Cubic polynomial"), lty = 1:3, lwd = 2, bty = "n")

Within the range of the gaugings the curves barely differ. They part company beyond it; vignette("uncertainty") takes that up.

A curve in two segments

Where the control changes, for example when the water rises out of the channel onto a floodplain, one power law is not enough. rc_2seg_powerlaw() fits two power laws that meet at a breakpoint stage, kk.

The Ardèche at Sauze, from the RBaM package, has such a change. RBaM calls its columns H, Q and uQ; here they get the names used in this package. Each gauging comes with its standard uncertainty, in cubic meters per second.

sauze <- tibble::tibble(
  stage = RBaM::SauzeGaugings$H,
  discharge = RBaM::SauzeGaugings$Q,
  uncertainty_sd = RBaM::SauzeGaugings$uQ
)
plot(
  stage ~ discharge,
  data = sauze,
  xlab = "Discharge (m³/s)",
  ylab = "Stage (m)"
)

The reported uncertainties give the variances directly, through var_spec(). Below the breakpoint, h<kh < k, the curve is a single power law, Q=a1(h−c1)b1Q = a_1 (h - c_1)^{b_1}. How the two segments combine above it, h≥kh \ge k, is set by combine. With "replace" (the default), the upper power law takes over from the lower one:

Q=a2(h−c2)b2,where a2=a1(k−c1)b1(k−c2)b2, Q = a_2 (h - c_2)^{b_2}, \qquad \text{where } a_2 = \frac{a_1 (k - c_1)^{b_1}}{(k - c_2)^{b_2}},

so that the two meet at the breakpoint. With "add", the upper power law adds to the discharge the lower one carries at the breakpoint, as when flow spills onto a floodplain:

Q=a1(k−c1)b1+a2(h−k)b2. Q = a_1 (k - c_1)^{b_1} + a_2 (h - k)^{b_2}.

fit_repl <- rc_2seg_powerlaw(
  discharge, stage,
  data = sauze,
  variance = var_spec(sauze$uncertainty_sd^2)
)
fit_add <- rc_2seg_powerlaw(
  discharge, stage,
  data = sauze,
  combine = "add",
  variance = var_spec(sauze$uncertainty_sd^2)
)
c(
  replace = fit_repl$curve_parameters$k,
  add = fit_add$curve_parameters$k
)
#>  replace      add
#> 1.621688 1.564349

The fit is sensitive to where the search for the breakpoint starts, so by default it tries several starting values and keeps the best. What each start led to is recorded:

fit_repl$kstart_search
#> # A tibble: 10 × 3
#>    kstart      k  loss
#>     <dbl>  <dbl> <dbl>
#>  1  0.573  0.713  139.
#>  2  0.924 NA       NA
#>  3  1.28   1.62   127.
#>  4  1.63  NA       NA
#>  5  1.98  NA       NA
#>  6  2.33  NA       NA
#>  7  2.68   1.62   127.
#>  8  3.03   1.62   127.
#>  9  3.39   1.62   127.
#> 10  3.74   1.62   127.
plot(stage ~ discharge, data = sauze, col = "grey50",
     xlab = "Discharge (m³/s)", ylab = "Stage (m)")
lines(stage ~ fit, data = predict(fit_repl), lwd = 2)
lines(stage ~ fit, data = predict(fit_add), lwd = 2, lty = 2)
abline(h = fit_repl$curve_parameters$k, col = "grey", lty = 3)
legend("bottomright", c("Upper segment replaces", "Upper segment adds"),
       lty = 1:2, lwd = 2, bty = "n")

Gaugings are sparse near the breakpoint at Sauze, so where exactly it lies is uncertain, which affects the limits on the curve there; see vignette("uncertainty").
